Product Details:

Payment & Shipping Terms:

Minimum Order Quantity:	1000 meters
Price:	Negotiable
Packaging Details:	Wooden roll, 2km/roll
Delivery Time:	3-5 working days
Payment Terms:	L/C, T/T, Western Union, MoneyGram, L/C
Supply Ability:	10KM per day

Contact Now

Detailed Product Description

Product Name:

Fiber Optic Cable Supplier

Model:

FTTH 4 Cores Drop Cable

Fiber Core:

4Cores

Application:

FTTH

High Light:

single mode fiber optic cable

FTTH 4 Cores Indoor Fiber Optic Cable Supplier

Parameters:

optical characteristics


		G. 652	G. 655	50/125um	62.5/125um
attenuation(+20º C)	@850nm			≤ 3.0db/km	≤ 3.0db/km
	@1300nm			≤ 1.0db/km	≤ 1.0db/km
	@1310nm	≤ 0.36db/km	≤ 0.4db/km
	@1550nm	≤ 0.22db/km	≤ 0.23db/km
	@850nm			≤ 600mhz. km	≤ 200mhz. km
bandwidth(class A)	@1300nm			≥ 1200mhz. km	≥ 600mhz. km
numerical Aperture				0.200± 0.015na	0.275± 0.015na
cable cut-off waveleng th xcc				≤ 1620nm	≤ 1450nm
storage/operating temperature: -40º C to +70º C

Features:

Small diameter, light weight, good practical applicability.
Simple and reasonable structure, has good resist compression, tensile and ageing resistance
Groove design, easy to strip jacket, simplify install and maintain
Use ITU G.657 standard core, and has the best cost performance of the same type products

Application:
