N / A Connector Optical Fiber Bragg Grating , High Accuracy Chirped Bragg Grating

Large Image : N / A Connector Optical Fiber Bragg Grating , High Accuracy Chirped Bragg Grating

Product Details:

Place of Origin:	China
Brand Name:	Haiyu Optical
Certification:	CE, ISO9001, Rohs
Model Number:	HYG-FBG-Chirp-004

Payment & Shipping Terms:

Minimum Order Quantity:	1 pcs
Price:	Negotiable
Packaging Details:	each packed in pe bag, 400-600pcs/carton
Delivery Time:	2-3 working days
Payment Terms:	L/C, T/T, Western Union, MoneyGram, L/C
Supply Ability:	1000pcs per day

Contact Now

Detailed Product Description

Product Name:	Fiber Bragg Grating	Fiber Type:	SMF-28e
Material:	Plastic,optical Fiber	Wavelength:	1625 -1650nm
Connector:	N/a	Operating Temperature:	-25~65
Accuracy:	0.1%	Application:	Dispersion Compensator
Highlight:	fiber optic bragg grating sensors , fbg fiber optic sensor

1650nm chirp FBG Optical Fiber Bragg Grating

Optical parameter:

item	parameter		specification	unit	Remarks
1	wavelength range	Pass band	1260~1625	nm	-
1	wavelength range	Reflect band	1644.5~1655.5	nm	-
2	Pass band	IL	≤1.0	dB	@1260~1360
			≤1.0	dB	@1460~1600
			≤2.5	dB	@1600~1625
		ORL	＞35	dB	@1260~1580
			＞30	dB	@1580~1620
			＞20	dB	@1620~1625
3	Reflect band	IL	＞21	dB	@1644.5~1655.5
3	Reflect band	ORL	≤1.0	dB	@1644.5~1655.5
4	PDL		≤0.4	dB	@1260~1600
5	Ripple		≤0.6	dB	@1644.5~1655.5
6	TDL		≤0.5	dB	@1260~1600

The product is used for two models, FBG-1650-S and FBG-1650-D.

FBG-1650-S is a traditional chirp grating with directionality, which satisfies parameters above in one direction.

The FBG-1650-D is a bidirectional chirped grating that satisfies parameters above in both directions.

Description:

The FBG is a fiber grating with a linear variation of the refractive index modulation period along the core direction. a large bandwidth is its main feature, which can generally reach several nanometers or tens of nanometers.

Characteristics:

● High stability and reliability

● Remote real-time detection

● Low insertion loss

● Easy connection for adapter structure

● Compliant with Telcordia GR-326-CORE, Telcordia GR-1221-CORE

● Compliant with RoHS

Working/storage conditions:

Parameter	Specification	Unit
Working temperature	-25 ~ +65	°C
Working humidity	5~95	%RH
Storage temperature	-40 ~ +85	°C
Storage humidity	5~95	%RH
